Table 3-1 Major component spare part information (continued)
Item Component Spare part number
For use in Saudi Arabia L96518-171
For use in Slovenia L96518-BA1
For use in South Korea L96518-AD1
For use in Spain L96518-071
For use in Switzerland L96518-BG1
For use in Taiwan L96518-AB1
For use in Thailand L96518-281
For use in the Ukraine L96518-BD1
For use in the United Kingdom L96518-031
For use in the United States L96518-001
(3) Touchpad:
In ash silver nish M02168-001
In natural silver nish L96507-001
In warm gold nish M02167-001
Touchpad cable (not illustrated) L96500-001
(4) Touchpad bracket (not available as a spare part)
(5) Power connector cable L96502-001
(6) Fingerprint reader:
In ash silver nish L98208-001
In natural silver nish L96504-001
In warm gold nish L98207-001
Fingerprint reader cable (not illustrated) L96499-001
(7) Fingerprint reader bracket (not available as a spare part)
(8) Speakers (include left and right speakers, cables, and 2 rubber isolators) L96508-001
(9) Connector board (includes USB port and audio-out (headphone)/audio-in (microphone) combo jack) L96503-001
Connector board cable (not illustrated) L96501-001
(10) System board (includes processor, graphics subsystem with UMA memory, and replacement thermal material):
For use only on computer models equipped with WWAN capability:
Equipped with an Intel Core i5-1035G1 processor and the Windows 10 operating system L96512-601
Equipped with an Intel Core i5-1035G1 processor and a non-Windows 10 operating system L96512-001
For use only on computer models not equipped with WWAN capability:
Equipped with an Intel Core i7-1065G7 processor and the Windows 10 operating system L96513-601
Equipped with an Intel Core i7-1065G7 processor and a non-Windows 10 operating system L96513-001
28 Chapter 3 Illustrated parts catalog
