Fingerprint reader
Table 5-13 Speaker spare part information
Description Spare part number
In ash silver nish L98208-001
In natural silver nish L96504-001
In warm gold nish L98207-001
Before removing the ngerprint reader, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 39), and then remove the following components:
a. Battery (see Battery on page 41)
b. Solid-state drive (see Solid-state drive on page 44)
c. Fan (see Fan on page 60)
d. System board (see System board on page 62)
Remove the ngerprint reader:
1. Remove the three Phillips M2.0×1.9 broad head screws (1) that secure the ngerprint reader and bracket
to the keyboard/top cover.
2. Remove the ngerprint reader bracket (2) .
70 Chapter 5 Removal and replacement procedures
