Display components
Table 3-2 Display component spare part information
Item Component Spare part number
(1) Display panel assembly (includes display bezel and display panel):
14.0 in, FHD, antiglare, UWVA, 400 nits touchscreen display panel assembly L96516-001
14.0 in, FHD, antiglare, UWVA, 250 nits touchscreen display panel assembly L96515-001
14.0 in, HD, antiglare, SVA, 220 nits touchscreen display panel assembly L96517-001
Display adhesive (not illustrated, used to attach display panel assembly to display back cover) L97984-001
(2) Display panel cable:
For use only on computer models equipped with WWAN capability L96497-001
For use only on computer models not equipped with WWAN capability L96496-001
(3) Sensor board L96506-001
(4) Touch control board (includes double-sided adhesive) L96505-001
(5) Display hinges (2, includes left and right hinges):
For use only on computer models equipped with an FHD display panel assembly L96494-001
For use only on computer models equipped with an HD display panel assembly L98206-001
(6) Display hinge cover (2, includes left and right hinge covers):
For use only on computer models equipped with an FHD display panel assembly L97985-001
For use only on computer models equipped with an HD display panel assembly L98205-001
(7) Wireless Antenna Kit (includes antenna cables and transceivers):
Display components 31
