Memory module
Table 5-6 Memory module spare part information
Description Spare part number
16 GB (DDR4-3200 MHz, 1.2 v) L67710-005
8 GB (DDR4-3200 MHz, 1.2 v) L46598-005
4 GB (DDR4-3200 MHz, 1.2 v) L83673-005
Before removing the memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 39).
5. Remove the battery (see Battery on page 41).
Remove the memory module:
1. Detach the memory module shield (1) from the retention clips built onto the system board.
2. Remove the memory module shield (2).
3. Spread the retention tabs (1) on either side of the memory module. (The memory module tilts up.)
Component replacement procedures 49
