HP ProCurve 2910al Series User Manual

1-15
Introducing the Switch
Features
Introducing the Switch
Features
Figure 2. Front of the al 10-GbE CX4 Module
The al Modules have the following features:
■ Connectivity ports.
■ LEDs that provide information for each port on the link and mode status.
■ LED that provides information on module status.
■ “hot swap transceiver” support—you can add, replace, or change the type
of any of the transceivers that you use in the SFP+ module ports, without
having to first remove the module, and without having to shut down the
switch.
Standards adherence:
■ IEEE 802.3ak CX4
■ IEEE 802.3ae XAUI
HP ProCurve 10-GbE CX4 al Module
Module Status
LEDs
Retaining screw
Copper CX4 port connections
Link and Mode LEDs
(one pair per port)

HP ProCurve 2910al Series Specifications

General

Model	HP ProCurve 2910al Series
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 3
Form Factor	Rack-mountable, 1U
Layer 3 Routing	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 or 48 10/100/1000 ports
Uplink Ports	4 SFP (mini-GBIC) slots
Power over Ethernet (PoE)	Available on PoE+ models (2910al-24G-PoE+ and 2910al-48G-PoE+)
Management	Web, SNMP, CLI
MAC Address Table Size	16, 000 entries
Routing Protocol	RIP
Power Supply	Internal power supply (AC)
Jumbo Frame Support	Yes (up to 9220 bytes)
Weight	4.9 kg
Power Consumption	Varies by model (typically 30-60W)
Operating Temperature	0°C to 45°C
VLAN Support	Yes (up to 512 VLANs)
