HP ProCurve 2910al Series User Manual

2-1
Installing the Switch
2
Installing the Switch
The HP ProCurve 2910al Switches come with an accessory kit that includes
the brackets for mounting the switch in a standard 19-inch telco rack, in an
equipment cabinet, and with rubber feet that can be attached so the switch
can be securely located on a horizontal surface. The brackets are designed to
allow mounting the switch in a variety of locations and orientations. For other
mounting options contact your local ProCurve authorized network reseller or
ProCurve representative. This chapter shows how to install the switch.
Caution If the switch is to be shipped in a rack, be sure to use only an HP 10K rack.
Mount the switch using rail kit, ProCurve 1U RK MT SWITCH 10K ALL, part
number 356578-B21 and shelf kit AB469A, HP rx 16/26 Factory Rackmount
Shelf Kit. Both kits must be used. Otherwise you will void the warranty.
Included Parts
The 2910al Switches have the following components shipped with them:
■ HP ProCurve Switch Quick Setup sheet
■ HP ProCurve Switches General Safety and Regulatory Information
booklet
■ 2910al Switch Specific Safety and Regulatory Information sheet
■ Read Me First
■ Customer Support/Warranty booklet
■ Console cable (5188-3836)

HP ProCurve 2910al Series Specifications

General

Model	HP ProCurve 2910al Series
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 3
Form Factor	Rack-mountable, 1U
Layer 3 Routing	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 or 48 10/100/1000 ports
Uplink Ports	4 SFP (mini-GBIC) slots
Power over Ethernet (PoE)	Available on PoE+ models (2910al-24G-PoE+ and 2910al-48G-PoE+)
Management	Web, SNMP, CLI
MAC Address Table Size	16, 000 entries
Routing Protocol	RIP
Power Supply	Internal power supply (AC)
Jumbo Frame Support	Yes (up to 9220 bytes)
Weight	4.9 kg
Power Consumption	Varies by model (typically 30-60W)
Operating Temperature	0°C to 45°C
VLAN Support	Yes (up to 512 VLANs)
