Installing the Switch
Installation Procedures
Installing the Switch
Installing the Interconnect Kit
The Interconnect Kit consists of two, 1-port 10 Gigabit switch expansion modules
(J9165A) and one 0.5 meter cable used specifically for this interconnect kit. These
modules have 1 fixed CX4 port each. The interconnect kit is used for 10-GbE (high
speed) connectivity.
Figure 2-6. Example using one Interconnect kit to connect two switches
Figure 2-7. Example using two Interconnect kits to connect three switches

HP ProCurve 2910al Series Specifications

General

Model	HP ProCurve 2910al Series
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 3
Form Factor	Rack-mountable, 1U
Layer 3 Routing	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 or 48 10/100/1000 ports
Uplink Ports	4 SFP (mini-GBIC) slots
Power over Ethernet (PoE)	Available on PoE+ models (2910al-24G-PoE+ and 2910al-48G-PoE+)
Management	Web, SNMP, CLI
MAC Address Table Size	16, 000 entries
Routing Protocol	RIP
Power Supply	Internal power supply (AC)
Jumbo Frame Support	Yes (up to 9220 bytes)
Weight	4.9 kg
Power Consumption	Varies by model (typically 30-60W)
Operating Temperature	0°C to 45°C
VLAN Support	Yes (up to 512 VLANs)
