HP ProCurve 2910al Series User Manual

A-1
Switch Specifications
A
Switch Specifications
Physical
Electrical
The switch automatically adjusts to any voltage between 100-127 and 200-240
volts and either 50 or 60 Hz.
Environmental
2910al-24G (J9145A) 2910al-48G (J9147A)
2910al-24G-PoE+ (J9146A) 2910al-48G-PoE+ (J9148A)
Width: 44.19 cm (17.4 in) 44.19 cm (17.4 in) 44.19 cm (17.4 in) 44.19 cm (17.4 in)
Depth: 36.57 cm (14.4 in) 36.57 cm (14.4 in) 36.57 cm (14.4 in) 36.57 cm (14.4 in)
Height: 4.4 cm (1.7 in) 4.4 cm (1.7 in) 4.4 cm (1.7 in) 4.4 cm (1.7 in)
Weight: 4.95 kg (10.92 lbs) 5.08 kg (11.2 lbs) 5.59 kg (12.34 lbs) 5.88 kg (12.96 lbs)
2910al-24G
(J9145A)
2910al-48G
(J9147A)
2910al-24G-PoE+
(J9146A)
2910al-48G-PoE+
(J9148A)
AC voltage: 100-127/200-240 volts 100-127/200-240 volts 100-127/200-240 volts 100-127/200-240 volts
Maximum current: 1.7A/0.9A 2.10A/1.1A 6.1A/3.1A 6.4A/3.2A
Frequency range: 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
All four models Operating Non-Operating
Temperature: 0°C to 55°C (32°F to 131°F) -40°C to 70°C (-40°F to 158°F)
Relative humidity:
(non-condensing)
15% to 95% at 40°C (104°F) 15% to 90% at 65°C (149°F)
Maximum altitude: 3.0 km (10,000 ft) 3.0 km (10,000 ft)

HP ProCurve 2910al Series Specifications

General

Model	HP ProCurve 2910al Series
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 3
Form Factor	Rack-mountable, 1U
Layer 3 Routing	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 or 48 10/100/1000 ports
Uplink Ports	4 SFP (mini-GBIC) slots
Power over Ethernet (PoE)	Available on PoE+ models (2910al-24G-PoE+ and 2910al-48G-PoE+)
Management	Web, SNMP, CLI
MAC Address Table Size	16, 000 entries
Routing Protocol	RIP
Power Supply	Internal power supply (AC)
Jumbo Frame Support	Yes (up to 9220 bytes)
Weight	4.9 kg
Power Consumption	Varies by model (typically 30-60W)
Operating Temperature	0°C to 45°C
VLAN Support	Yes (up to 512 VLANs)
