HP ProCurve 2910al Series User Manual

2-11
Installing the Switch
Installation Procedures
Installing the Switch
4. Mount the Switch
After the switch passes self test, it is ready to be mounted in a stable location.
The 2910al Switches can be mounted in these ways:
Rack or Cabinet Mounting
The 2910al Switches are designed to be mounted in any EIA-standard 19-inch
telco rack or communication equipment cabinet. Note the mounting brackets
have multiple mounting holes and can be rotated allowing for a wide variety
of mounting options. Secure the rack in accordance with the manufacture’s
safety guidelines.
WARNING For safe operation, please read the mounting precautions on
page 2-3, before mounting a switch.
Equipment
Cabinet
Note
The 12-24 screws supplied with the switch are the correct threading for
standard EIA/TIA open 19-inch racks. If you are installing the switch in an
equipment cabinet such as a server cabinet, use the clips and screws that came
with the cabinet in place of the 12-24 screws that are supplied with the switch.
Complete step 1, and plan which four holes you will be using in the cabinet
and install all four clips. Then proceed to step 2.
Rack Mounting the Switch
1. Use a #1 Phillips (cross-head) screwdriver and attach the mounting
brackets to the switch with the included 8-mm M4 screws. Remember to
use the correct accessory kit for your switch, see page 2-1.
Mounting Location Non-PoE Switches PoE Switches
In a rack or cabinet Yes Yes
On a horizontal surface Yes Yes
On a wall No No

HP ProCurve 2910al Series Specifications

General

Model	HP ProCurve 2910al Series
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 3
Form Factor	Rack-mountable, 1U
Layer 3 Routing	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 or 48 10/100/1000 ports
Uplink Ports	4 SFP (mini-GBIC) slots
Power over Ethernet (PoE)	Available on PoE+ models (2910al-24G-PoE+ and 2910al-48G-PoE+)
Management	Web, SNMP, CLI
MAC Address Table Size	16, 000 entries
Routing Protocol	RIP
Power Supply	Internal power supply (AC)
Jumbo Frame Support	Yes (up to 9220 bytes)
Weight	4.9 kg
Power Consumption	Varies by model (typically 30-60W)
Operating Temperature	0°C to 45°C
VLAN Support	Yes (up to 512 VLANs)
