HP ProCurve 2910al Series User Manual

2-15
Installing the Switch
Installation Procedures
Installing the Switch
Installing or Removing the Optical Media Converter
You can connect an Optical Media Converter (OMC) to the fixed ports only.
Use only HP ProCurve OMCs.
Installing the OMC:
1. Connect the OMC to the fixed port.
2. Push it until it clicks.
Figure 2-12. Installing an OMC
The OMC has a single bi-color LED to indicate power and link. The LED is
orange when the OMC has power but no link. The LED turns green when a
link is established.
Removing the OMC:
1. Disconnect the network cable from the OMC before removing it from the
module.
2. Grasp the extractor handle and pull straight out.
Extractor handle

HP ProCurve 2910al Series Specifications

General

Model	HP ProCurve 2910al Series
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 3
Form Factor	Rack-mountable, 1U
Layer 3 Routing	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 or 48 10/100/1000 ports
Uplink Ports	4 SFP (mini-GBIC) slots
Power over Ethernet (PoE)	Available on PoE+ models (2910al-24G-PoE+ and 2910al-48G-PoE+)
Management	Web, SNMP, CLI
MAC Address Table Size	16, 000 entries
Routing Protocol	RIP
Power Supply	Internal power supply (AC)
Jumbo Frame Support	Yes (up to 9220 bytes)
Weight	4.9 kg
Power Consumption	Varies by model (typically 30-60W)
Operating Temperature	0°C to 45°C
VLAN Support	Yes (up to 512 VLANs)
