HP ProCurve 2910al Series User Manual

3-6
Getting Started With Switch Configuration
Using the IP Address for Remote Switch Management
Getting Started With Switch
Configuration
The operating systems, web browsers, and Java support required to manage
the switch through the browser interface are listed in the following table:
The following illustration shows a typical web browser interface screen.
For more information on using the web browser interface, see the Manage-
ment and Configuration Guide, which is on the ProCurve Website at
www.procurve.com/manuals.
An extensive help system is also available for the web browser interface. To
access the help system though, the subnet on which the switch is installed
must have access to the internet, or ProCurve Manager needs to be installed
on a network management station that is on the subnet.
Operating System Internet Explorer Java Version
Windows 2000 SP4 5.5 SP2, 6.0 SP1 1.3.1_12 and 1.4.2_05
Windows XP SP1a 6.0 SP1 1.3.1_12 and 1.4.2_05
Windows Server 2003 6.0 SP1 1.3.1_12 and 1.4.2_05
PoE Status
1
Pr
oCur
ve Switch 2910al-48G
J914
7A
h29
1
0al-48G - S
atus: Inf
ormation
Pr
oCur v
e Switc
HP

HP ProCurve 2910al Series Specifications

General

Model	HP ProCurve 2910al Series
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 3
Form Factor	Rack-mountable, 1U
Layer 3 Routing	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 or 48 10/100/1000 ports
Uplink Ports	4 SFP (mini-GBIC) slots
Power over Ethernet (PoE)	Available on PoE+ models (2910al-24G-PoE+ and 2910al-48G-PoE+)
Management	Web, SNMP, CLI
MAC Address Table Size	16, 000 entries
Routing Protocol	RIP
Power Supply	Internal power supply (AC)
Jumbo Frame Support	Yes (up to 9220 bytes)
Weight	4.9 kg
Power Consumption	Varies by model (typically 30-60W)
Operating Temperature	0°C to 45°C
VLAN Support	Yes (up to 512 VLANs)
