Illustrated parts catalog 20
Item Description Spare part
number
Customer self
repair (on page
6
)
b) M.2 SSD module
—
—
c) SATA cable* — —
d) Low-profile board bracket* — —
10
SATA M.2 SSD dual module enablement kit 797908-001 Optional
2
a) M.2 SSD enablement board — —
b) M.2 SSD modules (2) — —
c) SATA cables (2) — —
d) Low-profile board bracket*
—
—
11
HP RPS backplane 784636-001 Optional
2
12
HP 800-W/900-W Gold AC Power Input Module 754376-001 Mandatory
1
13
HP 550-W Power Supply (non-hot-plug) 766879-001 Optional
2
14
Hot-swap fan 779093-001 Mandatory
1
15
8-bay LFF hot-plug drive backplane 779083-001 Optional
2
16
4-bay LFF hot-plug drive backplane 779096-001 Optional
2
17
8-bay SFF hot-plug drive backplane 780971-001 Optional
2
18
Front I/O assembly for LFF chassis using thumbscrew
rack ears
779088-001 Optional
2
19
Front I/O assembly for SFF chassis using thumbscrew
rack ears
779089-001 Optional
2
20
Quick-release latch rack ear assembly 779090-001 Optional
2
21
4-bay LFF non-hot-plug drive cable assembly (includes
Mini-SAS and drive power cables)
782466-001 Mandatory
1
22
8-bay LFF non-hot-plug drive cable assembly (includes
Mini-SAS and drive power cables)
782458-001 Mandatory
1
23
HP Smart Storage Battery 750450-001 Mandatory
1
24
System board (include alcohol pad and thermal
compound)
779094-001 Optional
2
25
DIMMs — —
a) 4 GB, single-rank x8 PC4-2133P-R* 804842-001 Mandatory
1
b) 4 GB, single-rank x8 PC4-2133R-15 774169-001 Mandatory
1
c) 8 GB, single-rank x4 PC4-2133R-15* 774170-001 Mandatory
1
d) 8 GB, single-rank x8 PC4-2133P-R* 804843-001 Mandatory
1
e) 8 GB, dual-rank x8 PC4-2133P-R* 774171-001 Mandatory
1
f) 16 GB, dual-rank x4 PC4-2133R-15* 774172-001 Mandatory
1
g) 16 GB, dual-rank x4 PC4-2133P-L* 774173-001 Mandatory
1
h) 32 GB, dual-rank x4 PC4-2133P-R* 774175-001 Mandatory
1
i) 32 GB, quad-rank x4 PC4-2133P-L* 774174-001 Mandatory
1
26
Processors (include alcohol pad and thermal
compound)
— —
a) 1.60-GHz Intel Xeon E5-2603 v3, 6C, 85 W 762441-001 Optional
2
b) 1.80-GHz Intel Xeon E5-2630L v3, 8C, 55 W* 762459-001 Optional
2
