Diagnostic tools 90
For additional information, see the following documents:
• HP iLO 4 User Guide — See the HP website (http://www.hp.com/go/ilo/docs).
• HP ProLiant Gen9 Troubleshooting Guide, Volume I: Troubleshooting — See "Troubleshooting
Resources (on page 87)."
Integrated Management Log
The IML records hundreds of events and stores them in an easy-to-view form. The IML timestamps each event
with 1-minute granularity.
You can view recorded events in the IML in several ways, including the following:
• From within HP SIM
• From within HP UEFI System Utilities (on page 90)
• From within the Embedded UEFI shell
• From within operating system-specific IML viewers:
o For Windows: IML Viewer
o For Linux: IML Viewer Application
• From within the iLO 4 web interface
• From within HP Insight Diagnostics (on page 92)
HP UEFI System Utilities
The HP UEFI System Utilities is embedded in the system ROM. The UEFI System Utilities enable you to perform
a wide range of configuration activities, including:
• Configuring system devices and installed options
• Enabling and disabling system features
• Displaying system information
• Selecting the primary boot controller
• Configuring memory options
• Selecting a language
• Launching other pre-boot environments such as the Embedded UEFI Shell and Intelligent Provisioning
For more information on the HP UEFI System Utilities, see the HP UEFI System Utilities User Guide for HP
ProLiant Gen9 Servers on the HP website (http://www.hp.com/go/ProLiantUEFI/docs).
Scan the QR code located at the bottom of the screen to access mobile-ready online help for the UEFI System
Utilities and UEFI Shell. For on-screen help, press F1.
Using HP UEFI System Utilities
To use the System Utilities, use the following keys.
Action Key
Access System Utilities
F9 during server POST
