Removal and replacement procedures 66
4. Install the access panel.
5. Do one of the following:
o Slide the server into the rack.
o Install the server into the rack.
6. Power up the server.
For more information about battery replacement or proper disposal, contact an authorized reseller or an
authorized service provider.
Dedicated iLO management module
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
CAUTION: To prevent damage to electrical components, take the appropriate anti-static
precautions before beginning any installation, removal, or replacement procedure. Improper
grounding can cause electrostatic discharge.
To remove the component:
1. Power down the server (on page 27).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
o Extend the server from the rack (on page 28).
o Remove the server from the rack (on page 30).
4. Remove the access panel ("Access panel" on page 37).
5. If an expansion board is installed in the primary PCI riser cage, then remove the PCI riser cage
("Remove the PCI riser cages" on page 31).
