Server component identification 13
Item Description Connector
Color
7 Power cord connector N/A
8 Keyboard connector Purple
9 NIC 1 connector N/A
10 NIC 2 connector N/A
11 USB connectors (2) Black
12 Video connector Blue
Rear panel LEDs and buttons
Item Description LED
Color
Status
1 RJ-45 activity LED Green On or flashing = Network activity
Off = No network activity
2 RJ-45 link LED Green On = Linked to network
Off = Not linked to network
