Removal and replacement procedures 77
2.
Remove the power input module.
To replace the component, reverse the removal procedure.
Redundant power supply backplane
WARNING:
To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
CAUTION: To prevent damage to electrical components, take the appropriate anti-static
precautions before beginning any installation, removal, or replacement procedure. Improper
grounding can cause electrostatic discharge.
To remove the component:
1. Power down the server (on page 27).
2. Access the product rear panel (on page 30).
3. Release the power cord from the hook-and-loop strap.
4. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
5. Remove all installed power input modules.
