Illustrated parts catalog 15
Illustrated parts catalog
Mechanical components
Item Description Spare part number Customer self repair (on
page
5
)
1
Front bezel 667267-001 Mandatory
1
2
Second optical drive cage 670612-001 Optional
2
3
Fan cage 667255-001 Optional
2
4
Fan blank 667262-001 Mandatory
1
5
Fan louver 667258-001 Optional
2
6
PCI air baffles (2) 667280-001 Mandatory
1
7
System air baffle 667256-001 Mandatory
1
8
Bezel ear kit 667274-001 Mandatory
1
a) Bezel ear, right
b) Bezel ear, left*
