Installation 17
5.
Tighten the wing nuts or hex nuts.
6. Install the rear stabilization bracket using wing nuts. Wait until the unit is installed and the brackets are
adjusted before tightening the nuts.
Installing the UPS in a rack
Before installing the unit, review and adhere to all warnings provided in "Precautions (on page 13)."
WARNING: A risk of personal injury or damage to the equipment exists. Uneven loading of
equipment in the rack might cause the rack to become unstable. Install the heavier components
first, and then continue to populate the rack from the bottom to the top.
1. Install the mounting rails.
