HP R/T3000 G2 User Manual

Installation 18
2.
Install the mounting ears on the chassis using the screws provided.
3. With one person on each side, lift the chassis to rail level and slide the chassis on the mounting rails.
4. Attach the chassis to the rack using the supplied screws.
Connecting the battery leads
WARNING:
To prevent personal injury from electric shock or damage to the equipment, remove
the battery lead labels, and verify that the ERM circuit breakers are in the Off position.

HP R/T3000 G2 Specifications

General

Power Rating	3000VA/2700W
Rack Size	2U
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-15°C to 45°C
Form Factor	Rack-mountable/Tower
Battery Type	Sealed lead-acid (SLA)
Battery Recharge Time	3 hours
Transfer Time	4-6 ms
Humidity	0-95% non-condensing
Communication Interface	USB, Serial
Warranty	3 years
