HP R/T3000 G2 User Manual

Spares 64
Spares
Ordering spares
To order a spare, visit the HP website (http://www.hp.com/buy/parts).
To replace parts under warranty, contact an HP authorized service representative.
UPS spare parts list
Item Description Spare part number
1
UPS unit —
a) NA/JPN 638840-001
b) HV NA/JPN* 638841-001
c) INTL* 638842-001
2
UPS Network Module 636934-001
3
Battery module 517703-001
4
Mounting rails with screws* 419181-001
5
UPS/ERM mounting brackets* 582931-001
6
Cord retention clips (6)* 407409-001
7
Serial download cable* 397642-001
* not shown

HP R/T3000 G2 Specifications

General

Power Rating	3000VA/2700W
Rack Size	2U
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-15°C to 45°C
Form Factor	Rack-mountable/Tower
Battery Type	Sealed lead-acid (SLA)
Battery Recharge Time	3 hours
Transfer Time	4-6 ms
Humidity	0-95% non-condensing
Communication Interface	USB, Serial
Warranty	3 years
