HP R/T3000 G2 - Connecting the Battery Leads; Rotating the Logo Badge

Installation 33
Connecting the battery leads
WARNING:
To prevent personal injury from electric shock or damage to the equipment, remove
the battery lead labels, and verify that the ERM circuit breakers are in the Off position.
Rotating the logo badge
Gently pull out the logo badge, rotate it 90 degrees, and then replace it in the bezel.
