Table 4: HPE StoreOnce 4700 24TB Backup spares part numbers (SPN)
Part Description SPN
Processor (two per system) Intel Xeon E5-2690 Eight-Core 64-bit
processor - 2.90GHz. See note at the end
of this table.
670521-001
Processor (two per system) Intel Xeon E5-2680v2 Ten-Core 64-bit
processor - 2.8-GHz. See note at the end of
this table.
730235-001
Processor Heatsink Standard efficiency heatsink 662522-001
Power supply (two per system) 1200 W, Platinum Plus, 94% 660185-001
Motherboard System I/O board 662530-001
Memory DIMM (16 x 8 GB, eight per
processor)
8GB, 1600MHz, PC3-12800R-11,
DDR3-1600, Single-Rank, 1.5V, Dual In-
Line Memory Module (DIMM)
664691-001
Hard disk (two in the server unit) 1TB, 7,200 rpm, SFF, 6G, dual port 653954-001
1Gbit FlexLOM Ethernet Controller SPS-BD ETHERNET 1Gb 4P 331FLR
ADPTR
634025-001
RAID controller p1224 (two per
system)
SPS-PCA p1224 w/o Encryption 698465-001
Internal SAS cable (one per RAID
card)
CBL, ASSY, MINI SAS HD to MINI SAS,
Internal
729358-001
SuperCapacitor (one per RAID
card)
ASSY, CA/CAPACITOR,36",FL 660093-001
RAID cache (one per RAID card) PCA, DDR3 MINIDIMM MOD 244P 1Gx72 633542-001
Fibre Channel card (two per
system)
HP 8Gb Dual Channel PCI-e to Fibre
Channel Host Bus Adapter
489191-001( FC
SFP = 468508-001)
10 GbE card (one per system) HP NC552SFP Dual Port 10GbE Server
Adapter
615406-001
PCIe riser card PCA. SPS-BD RISER STORAGE 800611-001
HPE StoreOnce 4500 24 TB Backup
The following table contains the spare parts for the main components in the server unit. Up to three
storage expansion shelves may be added to the configuration. See HPE StoreOnce 4500/4700 (24TB)
and 4500 (48TB) Expansion Modules on page 12 for information about the hard disks in the storage
expansion shelf and the SAS cabling from the server unit to the expansion shelf.
10 HPE StoreOnce 4500 24 TB Backup
