3. Turn the chassis upside down. Align the hooks on the underside of the bottom cover with the slots
in the chassis and press the cover down and then forward until it locks in place.
Figure 2-6 Replacing the bottom cover
4. Replace the stand, if the thin client is to be used in the tower orientation.
Removing and replacing the battery
Before beginning the replacement process, review General hardware installation sequence on page 10
for procedures you should follow before and after installing or replacing hardware.
WARNING! You must remove the left side panel to access the battery. Before removing the side
access panel, ensure that the thin client is turned off and the power cord is disconnected from the
electrical outlet.
To remove and replace the battery:
1. Locate the battery on the system board.
14 Chapter 2 Hardware changes
