HP t610 Series - Rear Panel Components

Rear panel components
For more information, http://www.hp.com and search for your specific thin client model to find the
model-specific QuickSpecs.
Figure 1-2 HP t610 Thin Client rear panel components
(1) DVI-I connector for DVI-D and VGA output (6) Serial connector
(2) DisplayPort connector (7) PS/2 connectors (2)
(3) Ethernet RJ-45 connector (8) Power cord retention slot
(4) Universal serial bus (USB) connectors (2) 2.0 (9) Cable lock slot
(5) Universal serial bus (USB) connectors (2) 3.0 (10) Power connector
Figure 1-3 HP t610 PLUS Thin Client rear panel components
(1) DVI-I connector for DVI-D and VGA output (7) PS/2 connectors (2)
Rear panel components
