3. Remove the four Torx screws (1), slide the stand toward the top of the computer, and then lift
the stand off the computer (2).
NOTE: You can use a Torx or a flat-head driver to remove the screws.
Figure 7-2 Removing the stand
To replace the stand, reverse the removal procedures.
Weight (with integrated graphics) without stand: 8.75 kg (19.3 lbs)
Weight (with discrete graphics) without stand: 9.05 kg (20.0 lbs)
Stand 35
