Optical drive eject board
Description Spare part number
Optical drive eject board 652312-001
Optical drive eject cable, 190 mm 652299-001
The optical drive eject board is located under the left side cap. It is secured with one screw and has
one connector.
Figure 7-37 Optical drive eject board location
To remove the optical drive eject board:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 33).
2. Remove the left rear panel (see
Rear panels on page 46).
3. Remove the left side cap (see
Optical drive on page 62).
64 Chapter 7 Removal and Replacement Procedures

HP TouchSmart 9300 Elite Specifications

General

RAM	Up to 16 GB DDR3 SDRAM
Operating System	Windows 7 Professional
Touchscreen	Yes
Processor	Intel Core i5 or i7
Display	23-inch diagonal widescreen LCD with LED backlight
Storage	Up to 1 TB Hard Disk Drive or Solid State Drive
Graphics	Intel HD Graphics
Optical Drive	DVD+/-RW SuperMulti DL
Chipset	Intel Q67 Express
Audio	Integrated high-definition audio
Webcam	Integrated 2 MP webcam
Ports	USB 2.0, RJ-45, audio in/out
Networking	Gigabit Ethernet, Wi-Fi
