HP x360 310 G2 User Manual

c. Rotate the top of the hinges inward so that the hinges are at an angle, (1), and then remove the
hinges (2).
4. To remove the display hinge covers:
NOTE: The display hinge covers are available using spare part number 809541-001 for red HP Pavilion
x360 models, 809540-001 for silver HP Pavilion x360 models, 809542-001 for green HP Pavilion x360
models, 809828-001 for purple HP Pavilion x360 models, and 824135-001 for silver HP x360 310 G2
models.
a. Remove the Phillips PM2.0×3.0 screw (1) that secures the hinge cover to the hinge.
b. Separate the hinge cover from the hinge (2).
5. To remove the display cable:
NOTE: The display cable is available using spare part number 809576-001.
▲
Remove the cable from the tape and clips (1) that secure it to the display enclosure, and then lift
the display cable from the display enclosure (2).
Component replacement procedures 59

HP x360 310 G2 Specifications

General

Graphics	Intel HD Graphics
Processor	Intel Celeron N3060
RAM	4 GB DDR3L
Storage	500 GB HDD
Display	11.6-inch HD (1366 x 768)
Operating System	Windows 10 Home
Battery	3-cell Li-ion
Ports	HDMI, headphone/microphone combo
Wireless	Bluetooth 4.0
