HP Z210 Series User Manual

7. Align the guide screws with the slots on the chassis drive cage, press the hard drive down into the
bay, then slide it back until it stops and locks in place.
Figure 9-10 Installing the hard drive (drive carrier shown)
8. Rotate the drive cage and the power supply down to their normal positions.
9. Replace all components that were removed in preparation for component installation.
Installing a secondary HDD or media card reader into a Z210 SFF
You can install an 8.89 cm (3.5 in) hard drive underneath the 13.3 cm (5.25 in) optical drive. A
media card reader can also be installed at this location. If an optical drive is present, you must remove
it to install the hard drive.
To install a hard drive or media card in the drive cage:
1. Follow the procedures described in
Preparing for component installation on page 34 to prepare
the workstation for component installation.
2. Remove the front bezel.
3. Remove the optical disk drive if it is present. (See
Installing an optical drive in an HP Z210 SFF
Workstation on page 56.)
ENWW
Installing a hard disk drive
51

HP Z210 Series Specifications

General

Chipset	Intel C206 Chipset
Networking	Integrated Intel 82579LM Gigabit Ethernet
Processor Options	Intel Xeon E3-1200 series, Intel Core i3, i5, i7 processors
Memory	Up to 32 GB DDR3
Storage Options	SATA HDD or SSD
Graphics Options	Integrated Intel HD Graphics, NVIDIA Quadro, AMD FirePro
Operating System	Red Hat Enterprise Linux
Form Factor	Convertible Mini-Tower
Optical Drive	DVD-ROM, DVD+/-RW
Audio	Integrated HD audio
Expansion Slots	PCIe x16, PCIe x1, PCI
Ports	USB 2.0, USB 3.0, serial, parallel, PS/2
Power Supply	400W 90% efficient
