HP Z24n G3 - How to Order Replacement Parts; Ordering Power Boards; Connector Part Ordering

9
18
Scrw_M2×2.8_U2419H
2
19
Rear_Cover_Z24n
1
20
Side_USB_Holder_Z24f_Z24_Z27
1
21
Side USB Board Z Series
1
22
Scrw_Tap_Pan_M3*0.6_NI
1
23
OSD_Holder_Z24f_Z24_Z27
1
24
OSD Holder Board Z Series
1
25
OSD_Key_Z24f_Z24_Z27
1
26
Scrw_Tap_Pan_M3*0.6_NI
2
27
Z_Logo_48mm_Pet_Black
1
28
Assy Hige for Z24n G3
1
29
Scrw_Mec_Flat_M4L6_NI_STE
4
30
Pivot Cover for Z24n G3
1
31
Assy Stand Column for Z24n G3
1
32
Assy Base for Z24n G3
1
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part
number
Manufacturer part number
PWR BD MG24WHC-BNUL(C) Z24n G3 WT-LGD D
M97965-001
755.A3A02.0001
PWR BD MG24WHC-BNUU(C) Z24n G3 WT-AUO D
M97966-001
755.A3A02.0002
Capacitors and connectors are available for purchase from the following EU distributors:
 SUSCON : www.su-scon.com
 CAPXON: www.capxongroup.com
Connectors by manufacturer
Component
description
Location
identifier
Component
distributor
Distributer part number
Remark
HDMI
HDMI1
Switchcraft
Inc.
https://www.digikey.com
PN:
137-RAHHD19TR-ND
Modify the rear cover I/O metal and plastic.
DP
DP1
DP2
Molex
https://www.digikey.com
PN:
WM14328DKR-ND
1. Only DP1.1
2. Modify the rear cover I/O metal
3. Cut off the through hole
