HP Z24q G3 - Connector Repair; HDMI Connector Repair

15
NA
4) Lift the connector up and away from the PCB.
No
Connector repair
This procedure includes HDMI, Display Port, USB-B and USB-A connectors.
The connectors are on the main board (board part number 7ZB.08001.0007).
The connector identifiers are as follows:
Connector
Location
HDMI
HDMI1
DP
DP1,DP2
USB-B
USB1
USB-A
USB2,USB3
USB-A
USB4,USB5
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 10.
HDMI connector HDMI1
Repair the HDMI connector:
1) Use a soldering iron and a de-soldering pump to remove as much solder as possible from the pin.
