HP Z24q G3 User Manual

3
2 Monitor features
This chapter provides an overview of the monitor’s features.
Features
Depending on the model, your monitor might include the following features:
Display features
● 60.5 cm (23.8 in) diagonal viewable screen area with 2560 × 1440 resolution, plus full-screen
support for lower resolutions; includes custom scaling for maximum image size while preserving
original aspect ratio
● Nonglare screen with an LED backlight
● Wide color gamut to provide coverage of sRGB color spaces
● Nonglare panel with an LED backlight
● Wide viewing angle to allow viewing from a sitting or standing position, or when moving from side to
side
● Tilt, swivel, and height adjustment capabilities
● Pivot capability to rotate the monitor head from landscape to portrait orientation
● Removable stand for flexible monitor head mounting solutions
● DisplayPort and High–Definition Multimedia Interface (HDMI) video inputs
● USB cable provided to connect the monitor's USB hub to the USB port on the computer
● Plug and Play capability, if supported by your operating system
● 100 mm integrated VESA mounting
● Security cable slot provision on rear of monitor for optional security cable
● On-screen display (OSD) adjustments in several languages for easy setup and screen optimization
● HP Display Assistant software for adjusting monitor settings and enabling theft deterrence features
● High-bandwidth Digital Content Protection (HDCP) copy protection on all digital inputs
● Energy saver feature to meet requirements for reduced power consumption
NOTE: For safety and regulatory information, refer to the Product Notices provided in your documentation
kit. To access the latest user guides or manuals for your product, go to http://www.hp.com/support and
follow the instructions to find your product. Then select Manuals.

HP Z24q G3 Specifications

General

Haze rate	25 %
Color depth	10 bit
Color gamut	99 %
Pixel pitch	0.21 x 0.21 mm
Screen shape	Flat
Pixel density	123 ppi
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	-
Native aspect ratio	16:9
Maximum refresh rate	90 Hz
Display number of colors	1.07 billion colors
Digital vertical frequency	50 - 90 Hz
Digital horizontal frequency	30 - 140 kHz
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	DisplayHDR 400
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR, RUS
Product color	Silver
Market positioning	Business
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	74 W
Power consumption (standby)	0.5 W
Power consumption (typical)	34 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
DisplayPort version	1.4
Package depth	141 mm
Package width	625 mm
Package height	373 mm
Package weight	7400 g

Weight and Dimensions

Depth (with stand)	195 mm
Width (with stand)	538.4 mm
Height (with stand)	489.3 mm
Weight (with stand)	4800 g
Depth (without stand)	38.5 mm
Height (without stand)	313.7 mm
