11
Connectors by manufacturer
Component description
Location identifier
Component
distributor
Distributer part number
HDMI
CN5001
RS
SD-47151-001
(Molex)
DP
CN5101
Farnell
DP1RD20JQ1
(JAE)
DP2
CN5201
Farnell
DP1RD20JQ1
(JAE)
USB3.0-A
CN1002/CN1102/CN1104
RS
10117835-002LF
Amphenol ICC
USB 3.0-B
CN1001
RS
692221030100
Wurth Elektronik
USB type C
CN1801
RS
DX07S024JJ2R1300
JAE
RJ45
CN1201
tme
LMJ34788114NWGY
AMPHENOL
USB3.0-A
CN154
RS
10117836-002LF
(Amphenol ICC)
USB Type-C
CN152
RS
632722110112
WE)
NOTE: Rear cover and chassis need to be modified to hold connector. Connector may need modifications to
meet functional, safety and regulatory requirements accordingly if it doesn’t match exactly.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
Internal and External Power Supplies are available for purchase from the following EU distributor: EET
https://www.eetgroup.com/en-eu/
NOTE: HP continually improves and changes product parts. For complete and current information about
supported parts for your product, go to https://partsurfer.hp.com/Search.aspx, select your country or region, and
then follow the on-screen instructions.
