1) The HP Z32K G3 power board connector position is as follows:
2) Locate the part number location on the board
Connector repair
This procedure includes HDMI, DisplayPort, USB Type C, USB B type, RJ45, USB 3.0A connectors.
The connectors are on the main board (board part number CBPC1R4HPQ2)
The connectors’ identifiers are as follows:
Warning: After unplugging the
power supply, the capacitance
is still charged, do not touch
and discharge the capacitor.
