HP Z32k G3 Maintenance And Service Guide

18
Type-C
CN1801
USB 3.0A (1、2、3)
CN1002/CN1102/CN1104
DP2
CN5201
This procedure includes USB3.0 A, USB Type-C connectors.
The connectors are on the USB board (board part number USB1QA6)
The connectors’ identifiers are as follows:
Connector
Location
USB 3.0 A
CN154
USB Type-C
CN152
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 12.
Main Board
CN154
CN152

HP Z32k G3 Specifications

General

Color depth	10 bit
Pixel pitch	0.18 x 0.18 mm
Screen shape	Flat
Pixel density	140 ppi
Backlight type	Edge LED
Display diagonal	31.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	29 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 135 kHz
sRGB coverage (typical)	100 %
Display bezel technology	Micro-Edge
Display number of colors	1.07 billion colors
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
Pivot angle	-90 - 90 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR, RUS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	180 W
Power consumption (standby)	0.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, HDMI, Thunderbolt, USB Type-A to USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB upstream port type	USB Type-B, USB Type-C
USB Power Delivery up to	100 W
USB Type-A downstream ports quantity	4
Sustainability certificates	ENERGY STAR
HP segment	Business
Package depth	185 mm
Package width	816 mm
Package height	504 mm
Package weight	13700 g
Product color	Black, Silver

Weight and Dimensions

Depth (with stand)	217 mm
Width (with stand)	713.5 mm
Height (with stand)	604.9 mm
Weight (with stand)	9000 g
Depth (without stand)	47 mm
Height (without stand)	415.9 mm
