HP Z32k G3 Maintenance And Service Guide

26
“Input Signal Not
Found” is displayed on
the screen.
The monitor video cable is disconnected.
Connect the appropriate video
signal cable between the
computer and monitor. Be sure
that the computer power is off
while you connect the video
cable.
“Input Signal Out of
Range”is displayed on
screen.
Video resolution and/or refresh rate are set
higher than what the monitor supports.
Change the settings to a
supported setting.
The monitor is off but it
did not seem to enter
into sleep mode.
Auto-Sleep Mode is not turned on.
Open the OSD menu and
select Power. Then select
Auto- Sleep Mode and set
auto-sleep to On.
“OSD Lockout” is
displayed
The monitor’s OSD lockout function is
enabled.
Press and hold the Menu
button on the front bezel for
10 seconds to disable the OSD
Lockout function.
“Power Button
Lockout” is displayed.
The monitor's Power Button Lockout function
is enabled.
Press and hold the power
button for 10 seconds to
disable the Power Button
Lockout function.
The USB ports do not
work, but the monitor is
turned on.
There is no upstream USB connection.
Be sure that the host computer
is connected to the monitor
with a USB Type-C to USB
Type-C cable or a USB Type-C
to USB Type-A cable.
No power from the USB
Type- C or USB Type-A
ports when the monitor
is in sleep mode.
The monitor is in Power Saver mode.
Open the OSD menu, select
Power, and then change the
power mode to Performance.
The desktop computer
does not turn on.
The monitor is turned off.
Be sure that the monitor power
cord is plugged into an AC
outlet and press the monitor
power button.
The monitor is in sleep mode.
Press any key on the
keyboard or move the mouse
to exit sleep mode.
The monitor is in Power Saver mode.
Open the OSD menu, select
Power, and then change the
power mode to Performance.
The desktop computer is not connected to
the USB Type-C#1 port on the monitor.
Be sure that the computer is
connected to the USB Type-
C#1 port on the monitor.
NOTE: Desktop host
computers must be
connected to the USB Type-

HP Z32k G3 Specifications

General

Color depth	10 bit
Pixel pitch	0.18 x 0.18 mm
Screen shape	Flat
Pixel density	140 ppi
Backlight type	Edge LED
Display diagonal	31.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	29 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 135 kHz
sRGB coverage (typical)	100 %
Display bezel technology	Micro-Edge
Display number of colors	1.07 billion colors
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
Pivot angle	-90 - 90 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR, RUS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	180 W
Power consumption (standby)	0.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, HDMI, Thunderbolt, USB Type-A to USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB upstream port type	USB Type-B, USB Type-C
USB Power Delivery up to	100 W
USB Type-A downstream ports quantity	4
Sustainability certificates	ENERGY STAR
HP segment	Business
Package depth	185 mm
Package width	816 mm
Package height	504 mm
Package weight	13700 g
Product color	Black, Silver

Weight and Dimensions

Depth (with stand)	217 mm
Width (with stand)	713.5 mm
Height (with stand)	604.9 mm
Weight (with stand)	9000 g
Depth (without stand)	47 mm
Height (without stand)	415.9 mm
