HPE FlexNetwork 5130 EI Series Configuration Guide

70
Task Command
Display dynamic MLD snooping
group entries.
display mld-snooping group
[ ipv6-group-address |
ipv6-source-address ] * [
vlan
vlan-id ] [
verbose
] [
slot
slot-number ]
Display static MLD snooping group
entries.
display mld-snooping static
-
group
[ ipv6-group-address |
ipv6-source-address ] * [
vlan
vlan-id ] [
verbose
] [
slot
slot-number ]
Display dynamic router port
information.
display mld-snooping router-port
[
vlan
vlan-id ] [
slot
slot-number ]
Display static router port information.
display mld-snooping static-router-port
[
vlan
vlan-id ] [
slot
slot-number ]
Display statistics for the MLD
messages learned through MLD
snooping.
display mld-snooping statistics
Delete dynamic MLD snooping group
entries.
reset mld-snooping group
{ ipv6-group-address
[ ipv6-source-address ] |
all
} [
vlan
vlan-id ]
Delete dynamic router ports.
reset mld-snooping router-port
{
all
|
vlan
vlan-id }
Clear statistics for the MLD
messages learned through MLD
snooping.
reset mld-snooping statistics
MLD snooping configuration examples
IPv6 group policy and simulated joining configuration
example (for VLANs)
Network requirements
As shown in Figure 24, Router A runs MLDv1 and acts as the MLD querier, and Switch A runs MLDv1
snooping.
Configure a group policy to achieve the following goals:
• Host A and Host B receive only the IPv6 multicast data addressed to IPv6 multicast group
FF1E::101. In addition, IPv6 multicast data is uninterruptedly forwarded through
GigabitEthernet 1/0/3 and GigabitEthernet 1/0/4 of Switch A, even though Host A and Host B
temporarily fail.
• Switch A drops unknown IPv6 multicast data instead of flooding it in VLAN 100.
