90
Task Command
Display information about IPv6
multicast groups in IPv6 multicast
VLANs.
display ipv6 multicast-vlan
group
[ ipv6-source-address |
ipv6-group-address |
slot
slot-number |
verbose
|
vlan
vlan-id ] *
Display IPv6 multicast VLAN
forwarding entries.
display ipv6 multicast-vlan forwarding-table
[ ipv6-source-address [ prefix-length ] | ipv6-group-address
[ prefix-length ] |
slot
slot-number |
subvlan
vlan-id |
vlan
vlan-id ] *
Clear IPv6 multicast groups in IPv6
multicast VLANs.
reset ipv6 multicast-vlan
group
[ ipv6-group-address
[ prefix-length ] | ipv6-source-address [ prefix-length ] |
vlan
vlan-id ]
*
IPv6 multicast VLAN configuration examples
Sub-VLAN-based IPv6 multicast VLAN configuration
example
Network requirements
As shown in Figure 32:
• MLDv1 runs on Layer 3 device Switch A, and MLDv1 snooping runs on Layer 2 device Switch
B.
• Switch A acts as the MLD querier.
• The IPv6 multicast source sends IPv6 multicast data to IPv6 multicast group FF1E::101. Host A,
Host B, and Host C are receivers. They belong to VLAN 2 through VLAN 4, respectively.
Configure a sub-VLAN-based IPv6 multicast VLAN on Switch B to achieve the following goals:
• Switch A sends the IPv6 multicast data to Switch B through the IPv6 multicast VLAN.
• Switch B forwards the IPv6 multicast data to the receivers in different user VLANs.
Figure 32 Network diagram
