HPE FlexNetwork 5510 HI Series Openflow Configuration Guide

23
Support items Capabilities
address to the MAC address of the virtual interface of the VLAN to which the
output port belongs.
• Decrement TTL by one.
• Goto-Table—When the switch has multiple tables, the switch adds this
instruction by default if the controller does not deploy it.
• Write-Metadata—When the switch has multiple tables, the switch adds this
instruction by default if the controller does not deploy it.
MAC-IP flow table restrictions
Controller must follow the restrictions in Table 5 and Table 6 to deploy flow entries for MAC-IP flow
table. Otherwise, forwarding failure might occur.
Table 5 Restrictions for deploying Layer 2 flow entries for the MAC-IP flow table
Items Restrictions
Match fields
The destination MAC address cannot be MAC address of the switch to which the
flow entry is deployed.
Actions The output port must belong to the VLAN that is matched.
Table 6 Restrictions for deploying Layer 3 flow entries for the MAC-IP flow table
Items Restrictions
Match fields
The VLAN interface of the VLAN that is matched is in UP state.
The destination MAC address cannot be MAC address of the switch to which the
flow entry is deployed.
The destination IP address cannot be the IP address of the switch to which the
flow entry is deployed.
Actions
The specified output port must belong to the destination VLAN.
The destination MAC address cannot be MAC address of the switch to which the
flow entry is deployed.
If the switch modifies the source MAC address, the source MAC address must be
the MAC address of the VLAN interface of the VLAN to which the output port
belongs.
To deploy a Layer 3 flow entry, make sure the following requirements are met:
• The VLAN interface of the matched VLAN is in up state.
• The switch sends the controller a packet that indicates the VLAN interface functions as an
OpenFlow port. The link state and the MAC address of the VLAN interface are also included in
the packet.
The switch reports the VLAN interface deletion to the controller and the controller removes the
corresponding Layer 3 flow entry.
The controller ensures the correctness of Layer 3 flow entries. The switch does not check for the
restrictions for Lay 3 flow entries.
Table-miss flow entry of MAC-IP flow tables
The table-miss flow entry of a MAC-IP flow table supports the following output actions:
• Goto-Table—Direct the packet to the next table.
