HPE STOREONCE 5500

Item Description Status
9 Display* Error codes are displayed in hexadecimal format, see
Display messages on page 58
for more information
10 UID button/LED (Drawer 1) Blue = UID LED is enabled from the UID button
Blue flashing = System is in hard drive locate mode or an
enclosure firmware update is in progress
Off = UID LED is disabled
* If the GSI is amber, the system needs service. Activate the associated drawer UID button to view any
GSI error codes on the rear display.
IO module LEDs
IO module LED combinations
Blue Green Amber Meaning
Off Off Off No power
Off On, solid Off Powered on and healthy, normal operation
Blinking On, solid Off Locate IOM, not safe to remove
Blinking Off On, solid IOM fault, not safe to remove
On, solid On, solid Off Locate IOM, safe to remove
On, solid Off On, solid IOM fault, safe to remove
IO module port LED combinations
Left LED Right LED Meaning
Off Off No power, fault or no cable installed
Off Amber Powered on with no SAS link or cable installed but broken
Green Off Powered on, link high speed
Green Amber Powered on, link high low
Display messages
This section describes error messages that the customer may be able to resolve. If an error message is
displayed that is not included below, contact HPE Support.
58 IO module LEDs
