Appendix A Parameter Shenzhen Hpmont Technology Co., Ltd.
―88― HD3L Series Controller User Manual
Ref. Code
Function Setting Range Default Unit Attribute Setting
F01.02
Function code parameter
initialization
0: No operation
1: Restore to factory settings
2: Parameter download
3: Clear fault information
0 1
×
F01.03
Keypad EEPROM parameter
initialization
0: No operation
1: Parameter upload
0 1
○
F02: Start & Stop Parameters, on pages 48 - 49
F02.00 Start delay time 0.000 - 4.999s 0.000s 0.001s
×
F02.01 Brake open delay time 0.000 - 4.999s 0.000s 0.001s
×
F02.02
Retention time of start
zero-speed
0.000 - 4.999s 0.000s 0.001s
×
F02.03 Start speed 0.000 - 0.400m/s 0.000m/s 0.001m/s
×
F02.04 Retention time of start speed 0.000 - 4.999s 0.000s 0.001s
×
F02.05 Brake close delay time 0.000 - 4.999s 0.000s 0.001s
×
F02.06
Retention time of stop
zero-speed
0.000 - 4.999s 0.000s 0.001s
×
F02.07 Contactor close delay time 0.000 - 4.999s 0.000s 0.001s
×
F02.08 Start ramp time
0.000 - 2.000s
0.000: Ramp invalid
0.000s 0.001s
×
F02.09 Unused
F03: Acc / Dec Parameters, on pages 49 - 50
F03.00 Acc speed 0.020 - 9.999m/s
2
0.700m/s
2
0.001m/s
2
×
F03.01 Start Acc jerk 0.020 - 9.999m/s
3
0.350m/s
3
0.001m/s
3
×
F03.02 End Acc jerk 0.020 - 9.999m/s
3
0.600m/s
3
0.001m/s
3
×
F03.03 Dec speed 0.020 - 9.999m/s
2
0.700m/s
2
0.001m/s
2
×
F03.04 Start Dec jerk 0.020 - 9.999m/s
3
0.600m/s
3
0.001m/s
3
×
F03.05 End Dec jerk 0.020 - 9.999m/s
3
0.350m/s
3
0.001m/s
3
×
F03.06 Inspection Acc speed 0.020 - 9.999m/s
2
0.200m/s
2
0.001m/s
2
×
F03.07 Inspection Dec speed 0.020 - 9.999m/s
2
1.000m/s
2
0.001m/s
2
×
F03.08 Battery driven Acc speed 0.020 - 9.999m/s
2
1.000m/s
2
0.001m/s
2
×
F03.09 Battery driven Dec speed 0.020 - 9.999m/s
2
1.000m/s
2
0.001m/s
2
×
F03.10 Motor auto-tuning Acc speed 0.020 - 9.999m/s
2
0.100m/s
2
0.001m/s
2
×
F03.11 Motor auto-tuning Dec speed 0.020 - 9.999m/s
2
0.100m/s
2
0.001m/s
2
×
F03.12 Abnormal Dec speed 0.020 - 9.999m/s
2
1.000m/s
2
0.001m/s
2
×
F03.13 Stop Dec jerk 0.020 - 9.999m/s
3
0.350m/s
3
0.001m/s
3
×
F03.14 - F03.20 Unused
F04: Analogue Curve Parameters, on pages 50 - 51
F04.00 Setting curve
Units: AI1 setting curve
Tens: AI2 setting curve
Hundreds: AI3 setting curve
Thousands: AI4 setting curve
0: Line 1
1: Line 2
0000 1
×
