Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameter
HD3L Series Controller User Manual ―89―
Ref. Code
Function Setting Range Default Unit Attribute Setting
F04.01 Line 1 min. setting 0.0 - F04.03% 0.0% 0.1%
○
F04.02
Corresponding value of line 1
min. setting
0.0 - 100.0% 0.0% 0.1%
○
F04.03 Line 1 max. setting F04.01 - 100.0% 100.0% 0.1%
○
F04.04
Corresponding value of line 1
max. setting
0.0 - 100.0% 100.0% 0.1%
○
F04.05 Line 2 min. setting 0.0 - F04.07% 0.0% 0.1%
○
F04.06
Corresponding value of line 2
min. setting
0.0 - 100.0% 0.0% 0.1%
○
F04.07 Line 2 max. setting F04.05 - 100.0% 100.0% 0.1%
○
F04.08
Corresponding value of line 2
max. setting
0.0 - 100.0% 100.0% 0.1%
○
F05: Speed Parameters, on pages 51 - 53
F05.00 Multi-speed 0 0.000 - F00.02m/s 0.000m/s 0.001m/s
○
F05.01 Multi-speed 1 0.000 - F00.02m/s 0.000m/s 0.001m/s
○
F05.02 Multi-speed 2 0.000 - F00.02m/s 0.000m/s 0.001m/s
○
F05.03 Multi-speed 3 0.000 - F00.02m/s 0.000m/s 0.001m/s
○
F05.04 Multi-speed 4 0.000 - F00.02m/s 0.000m/s 0.001m/s
○
F05.05 Multi-speed 5 0.000 - F00.02m/s 0.000m/s 0.001m/s
○
F05.06 Multi-speed 6 0.000 - F00.02m/s 0.000m/s 0.001m/s
○
F05.07 Multi-speed 7 0.000 - F00.02m/s 0.000m/s 0.001m/s
○
F05.08 Inspection run speed 0.000 - 0.630m/s 0.200m/s 0.001m/s
○
F05.09 Battery driven run speed 0.000 - F00.02m/s 0.100m/s 0.001m/s
○
F05.10
Up forced speed switch
detection value
0.0 - 100.0% (F00.02) 97.0% 0.1%
○
F05.11
Down forced speed switch
detection value
0.0 - 100.0% (F00.02) 97.0% 0.1%
○
F05.12 FDT1 0.0 - 100.0% (F00.02) 90.0% 0.1%
○
F05.13 FDT2 0.0 - 100.0% (F00.02) 90.0% 0.1%
○
F05.14 FDT1 delay level 0.0 - 100.0% (F00.02) 1.0% 0.1%
○
F05.15 FDT2 delay level 0.0 - 100.0% (F00.02) 1.0% 0.1%
○
F05.16 Speed within FAR range 0.0 - 20.0% (F00.02) 1.0% 0.1%
○
F05.17 Over-speed setting 80.0 - 120.0% (F00.02) 115.0% 0.1%
×
F05.18 Over-speed detection time
0.0 - 2.0s
0.0: Not detect motor over speed
fault
0.2s 0.1s
×
F05.19
Detection value of speed
deviation
0.0 - 30.0% (F00.02) 20.0% 0.1%
×
F05.20
Detection time of speed
deviation
0.0 - 2.0s
0.0: Not detect the excessive speed
deviation fault of motor
1.0s 0.1s
×
F05.21 Unused
F05.22 Creeping speed 0.000 - 0.400m/s 0.050m/s 0.001m/s
○
A
