hpmont HD3L-4T5P5 User Manual

Appendix A Parameter Shenzhen Hpmont Technology Co., Ltd.
―90― HD3L Series Controller User Manual
Ref. Code
Function Setting Range Default Unit Attribute Setting
F05.23 - F05.25 Unused
F06: Weighing Compensation Parameters, on pages 53 - 54
F06.00 Pre-torque selection
0: No pre-torque
1: Analogue setting
2: DI setting
3: Digital pre-torque
0 1
×
F06.01 Up pre-torque bias 0.0 - 100.0% 50.0% 0.1%
×
F06.02 Down pre-torque bias 0.0 - 100.0% 50.0% 0.1%
×
F06.03 Up electrical pre-torque gain 0.000 - 9.000 1.000 0.001
×
F06.04 Up brake pre-torque gain 0.000 - 9.000 1.000 0.001
×
F06.05
Down electrical pre-torque
gain
0.000 - 9.000 1.000 0.001
×
F06.06 Down brake pre-torque gain 0.000 - 9.000 1.000 0.001
×
F06.07 Pre-torque digital setting -100.0 - 100.0% 10.0% 0.1%
×
F06.08 DI weighing signal 1 0.0 - 100.0% 10.0% 0.1%
×
F06.09 DI weighing signal 2 0.0 - 100.0% 30.0% 0.1%
×
F06.10 DI weighing signal 3 0.0 - 100.0% 70.0% 0.1%
×
F06.11 DI weighing signal 4 0.0 - 100.0% 90.0% 0.1%
×
F06.12 - F06.20 Unused
F07: Asyn. Motor Parameters, on pages 54 - 57
F07.00 Rated power of motor 0.2 - 400.0kW
Depend
on motor
0.1kW
×
F07.01 Rated voltage of motor 0V - HD3L rated voltage 1V
×
F07.02 Rated current of motor 0.0 - 999.9A 0.1A
×
F07.03 Rated frequency of motor 1.00 - 100.00Hz 50.00Hz 0.01Hz
×
F07.04 Rated RPM of motor 1 - 24000RPM 1440RPM 1RPM
×
F07.05
Power factor of motor
0.001 - 1.000
Depend
on motor
0.001
×
F07.06
Motor parameter auto-tuning 0: Auto-tuning is disabled
1: Stationary auto-tuning
2: Rotary auto-tuning
0 1
×
F07.07 Stator resistance of motor 0.000 - 65.535Ω
Depend
on motor
0.001Ω
×
F07.08 Rotor resistance of motor 0.000 - 65.535Ω 0.001Ω
×
F07.09 Leakage inductance of motor 0.0 - 6553.5mH 0.1mH
×
F07.10 Mutual inductance of motor 0.0 - 6553.5mH 0.1mH
×
F07.11
Idling excitation current of
motor
0.0 - 999.9A 0.1A
×
F07.12
Core saturation coefficient 1
of motor
0.00 - 0.50 (magnetic flux = 50%) 0.50 0.01
×
F07.13
Core saturation coefficient 2
of motor
0.00 - 0.75 (magnetic flux = 75%) 0.75 0.01
×
F07.14
Core saturation coefficient 3
of motor
0.00 - 1.20 (magnetic flux =
120%)
1.20 0.01
×
F07.15 Motor torque boost 0.1 - 30.0% 0.1% 0.1%
○
