− 25 −
Trouble
1. The terminal is
not fed smoothly.
The terminal is
not fed.
Cause
Corrective measure
Caution :
To carry out troubleshooting, be sure to detach the applicator from the crimping machine in prior.
8. Troubleshooting
Before starting troubleshooting, the following has to be checked.
1) Are the correct crimpers and anvils attached?
2) Is the applicable terminal used?
3) Is the electric cable that falls within the applicable range used?
(1) Troubles with respect to functions of the applicator
* Contact our Production Engineering Department for consultation for use or any unclear points.
8. 故障处理
请首先确认以下事项。
1) 夹紧器、砧台是否安装正规的零件。
2) 使用的端子是否是适合端子。
3) 使用的电线是否是适合范围内的电线。
(1) 供料器功能的故障
2. Terminal deforms
to take S-shape
during clamping.
1. The feed nger is
mounted out of position
and is not aligned with
the center of the pilot
hole.
2. Top of the feed nger has worn out.
3. Cam follower has worn out.
1. Scrap guard is attached to a wrong
position and comes in contact with the
reel terminal carrier.
2. Cut-off punch has scratches and
marks, impairing smooth up- and-
down movement of the terminal.
1. Re-adjsut the
mounting position
of the feed nger.
2. Replace the feed nger with a new one.
(Consult us for service.)
3. Replace the cam follower with a
new one.(Consult us for service.)
1. Re-adjust the attaching position
of the scrap guard.
2. Replace the cut-o punch with a
new one.
故障
1. 端子不能顺畅
传送。
原因
处理
1. 供料指的安装位置偏移，
没有对准卷盘端子传送的
操作杆孔的中心。
2. 供料指的前端磨损。
3. 凸轮磨损。
1. 废屑防护器的安装位置不正确，与卷盘端
子传送器相碰。
2. 切断钳上有伤痕，上下动作不灵活。
1. 重新调整供料指
的安装位置。
2.
请更换新的供料指。( 请与本公司联系。)
3. 请更换新的切断钳。( 请与本公司联系。)
1. 重新调整废屑防护器的安装位置。
2. 请更换新的切断钳。
2. 压接作业中，
传送器变形成
S 形。
参照页
P29 (3)
P29 (4)
P23
* 有关使用方法，如有不明之处，请与本公司生产技术部联系。
进行操作时、请一定从压接机上卸下供料器后再进行操作。
Related page
P29(3)
P29(4)
P23
注意
To Next Page
