HRS AP109A - Appendix; Major Component Names

− 31 −
9. Appendix
(1) Major component names
Item Product name Q’ty
36 Dummy 1
37 Anvil holder 1
38 Anvil holder pin 1
39 Shear plate 1
40 Wire anvil 1
41 Insulation anvil 1
42 Cut-o󰀨 punch 1
43 Cut-o󰀨 punch spring 1
44 Cut-o󰀨 die 1
45 Cut-o󰀨 die pin 1
46 Wire stopper 1
47 Carrier chute 1
48 Ram 1
49 Ram pin 1
50 Crimp height adjusting dial 1
51 Dial spring 1
52 Dial bolt 1
53 Dial pin 1
54 Dial bolt xing screw 1
55 Insulation crimp height adjusting dial 1
56 Feed cam 1
57 Shoulder screw 1
58 Shoulder spring 1
59 Crimper spacer 1
60 Wire crimper 1
61 Insulation crimper 1
62 Insulation spacer 1
63 Actuator 1
64 Actuator spring pin 1
65 Wire presser 1
66 Actuator pin 1
67 Actuator spring 1
68 Pin 1
69 Holder 1
70 Guide 1
Item Product name Q’ty
1 Frame 1
2 Base plate 1
3 Adapter plate 1
4 Mounting plate (A) 1
5 Mounting plate (B) 1
6 Adjust block (A) 1
7 Adjust block (B) 1
8 Adjust screw 1
9 Adjust block pin 1
10 Terminal guide 1
11 Terminal rail 1
12 Feed rod 1
13 Feed roller 1
14 Roller pin 1
15 Adjust rod 1
16 Pivot block 1
17 Retaining ring (A) 1
18 Guide plate 1
19 Spring anchor 1
20 Feed lever 1
21 Pivot bush 2
22 Pivot pin 1
23 Pivot bush spacer 1
24 Finger holder 1
25 Feed nger 1
26 Feed nger pin 1
27 Feed nger spring 1
28 Feed spring 1
29 Drug stock 1
30 Cam boss 1
31 Cam lever 1
32 Cam shaft 1
33 Drag stock bolt 2
34 Drag stock spring 2
35 Retaining ring (B) 1
