72
4.Check if there exists any slip thread or flaw on the open-groove
nut .
5..Disassemble the front tank and check whether the gears
Is engaged properly.
6..In case the choke is jammed,it must be dredged with a needle.If
the problem is not solved, replaced it.
7.If there are defects on sensors ,it must be checked and
maintained by a professional.
8. Gears are fragile commodities in transmission system.
4.4.1.2 Disassembly of fore bridge component:
1.Detach the two front wheel parts.
2.Removed front Disk Brake Clip, cotter pin, cushion and the
front wheel hub. (Figure 4-2-20)
Figure 4-2-20
3.Disassemble the fore bridge differential( Figure 4-2-20)
4、Take out the fore bridge from the frame
5、Release engine oil in the differential
6、Unplug the transmission shaft from the differential (Figure
4-2-19)
