Step 3 Route the arranged core wires through the RJ45 connector, as shown in Figure 5-60.
Figure 5-60 Routing core wires through the connector
Step 4 Use the crimping tool to crimp the connector, as shown in Figure 5-61.
Figure 5-61 Crimping the connector
Step 5 Neatly cut braid shields exposed out of the connector along the load bar, as shown in Figure
5-62.
