Huawei EchoLife HG8110 User Manual

Figure 3-6 Configuring the GPON FTTH multicast service
Multicast Source
OLT
LAN Switch
Optical splitter
U2000
STB
TV
BRAS
ONT
Procedure
l Add the ONT to the U2000 in profile mode.
1. Configure an MEF IP traffic profile.
a. Choose Configuration > Access Profile Management from the main menu. In
the dialog box that is displayed, choose Traffic Profile from the navigation tree.
b. Click the MEF IP Traffic Profile tab.
c. Right-click and choose Add Global Profile from the shortcut menu.
d. In the dialog box that is displayed, set the parameters.
– Name: FTTx
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
111
