Step 5 Select a required record from the ONT list, and then click the POTS User tab in the lower pane.
Step 6 View the user registration states in column Status and the user calling states in column Call
Status, as shown in the following figure.
Figure 4-10 Querying the status of a VoIP user
NOTE
The registration states and calling states are listed as follows:
l Registration states include Up, Initializing, Registering, Unregistering, Error, Testing,
Quiescent, and Disabled.
l Calling states include Idle, Calling, Ringing, Connecting, and InCall.
----End
4.5.4 Querying and Deleting VoIP Statistics
VoIP statistics include RTP statistics and calling statistics. This topic describes how to query
and delete VoIP statistics.
Prerequisite
l The user is a user with the operator authority or higher.
l The OLT and the NMS communicate with each other properly.
l The NMS is able to discover an online ONT and VoIP service parameters are configured.
Context
To query accurate VoIP statistics, delete the original VoIP statistics first.
Procedure
Step 1 In the Physical Map navigation tree on the Main Topology tab page, double-click the target
OLT, or select the target OLT, right-click, and choose NE Explorer.
Step 2 In the navigation tree, choose GPON > GPON Management.
Step 3 In the window on the right, choose GPON ONU.
Step 4 On the GPON ONU tab page, set the search criteria to find the GPON ONU records.
Step 5 Select a required record from the ONT list, and then click the POTS User tab in the lower pane.
Step 6 Query VoIP statistics.
1. Select a record from the list, right-click, and then choose Performance Statistic.
2. In the dialog box that is displayed, view the VoIP statistics, as shown in the following
figure.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 4 Maintenance and Troubleshooting
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
289
