3.3 Configuration by Using OLT Commands
This topic describes how to configure the Internet access service, VoIP service and IPTV service
by using OLT commands.
3.3.1 Data Plan
This topic plans the data in a unified manner for connecting to the OLT in the FTTH GPON
access mode for various example networks. The subsequent examples are configured based on
the following data plan.
Data Plan
Table 3-4 provides the unified data plan for configuring the HSI, IPTV, and VoIP services in
an FTTH network.
Table 3-4 Data plan for the FTTH GPON access
Service
Classificati
on
Item Data Remarks
Network
data
FTTH
l OLT PON port: 0/1/1
l ONT ID: 1-2
-
Service
VLAN
HSI service
l SVLAN: 100
l CVLAN: 10
-
IPTV service
l Multicast VLAN: 1000
l SVLAN: 1000
l CVLAN: 30
Generally, multicast
VLANs are divided
according to
multicast sources.
VoIP service
l SVLAN: 200
l CVLAN: 20
-
QoS
(priority)
HSI service Priority: 1; queue scheduling:
WRR
l Generally, the
QoS priorities
are VoIP service
> IPTV service >
Internet access
service in a
descending
order.
l Generally, the
priority is set on
the ONT, and the
OLT inherits the
priority set on
the ONT.
IPTV service
Priority: 4; queue scheduling:
WRR
VoIP service Priority: 6; queue scheduling:
PQ
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
129
