Page #31 background imageLoading...
Page #31 background image
No.
LED Status
Indication
PON LOS
2 Blinks quickly
(twice per
second)
Off The ONT is attempting to set up a
connection to the OLT.
3 Always on Off
The connection between the ONT
and the OLT is set up.
4 Off Blinks slowly
(once two
seconds)
The Rx optical power of the ONT is
lower than the optical receiver
sensitivity.
5
Blinks quickly
(twice per
second)
Blinks quickly
(twice per
second)
The OLT detects that the ONT is a
rogue ONT.
2.2 Typical Network Applications
This topic describes the typical network applications of the HG8010/HG8110/HG8240/
HG8245/HG8247/HG8447.
As a network terminal, the HG8010/HG8110/HG8240/HG8245/HG8247/HG8447 is deployed
at the GPON access layer and connects home users and SOHO users to the Internet through
optical upstream ports. On the local area network (LAN) side, the HG8010/HG8110/HG8240/
HG8245/HG8247/HG8447 provides abundant hardware ports to meet various network
requirements of home users and SOHO users.
Network Topology of the HG8010
Figure 2-25 shows the position of the HG8010 in a network.
Figure 2-25 Network topology of the HG8010
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 2 System Overview
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
23
